Product Overview
The calibration stand CS210 helps you calibrate pressure transmitters, pressure indicators, and both analog and digital pressure gauges in workshop and laboratory environments. It provides a stable base and includes all necessary pressure connections for the pressure source and reference pressure module. The stand also functions as a manifold with three G 1/8” female pressure ports: two with Bx 1215 male fittings and internal valves, one plugged. Maximum pressure 210 bar (3045 psi).
Standard delivery includes
- Calibration Stand with hand-tightened quick-connect G 1/2” female pressure port to secure the Device Under Test (DUT) in vertical position.
- Beamex 630 bar hose, 1 m / 39.37”
- O-ring set 6.3 × 2.4 mm (10 pcs) for sealing the DUT to G 1/2" pressure port
